典雅A系列
 |
Model | Dimension | Input Voltage |
Power | Luminous Flux |
Light Aource |
CRI | CCT | Power Factor |
包装资料 | ||
| 装箱率 | 外箱尺寸 | 毛重 | ||||||||||
| 4寸 | MDS-01A40W009-8309 | Φ135*H45mm 开孔102mm |
AC100-240V/50-60Hz | 9W± 0.9W | 720lm | SMD2835/ 0.2W(63PCS) | ≧80 | 3045± 175K | >0.9 | 12pcs | 52*16* 31.5 | 3.4kgs |
| MDS-01A40W009-8409 | 720lm | 3985± 275K | ||||||||||
| MDS-01A40W009-8509 | 765lm | 5028± 283K | ||||||||||
| 6寸 | MDS-01A60W015-8309 | Φ180*H45mm 开孔152mm |
AC100-240V/50-60Hz | 15W± 1.5W | 1200lm | SMD2835/ 0.2W(96PCS) | ≧80 | 3045± 175K | >0.9 | 12pcs | 52*21* 41 | 5.2kgs |
| MDS-01A60W015-8409 | 1200lm | 3985± 275K | ||||||||||
| MDS-01A60W015-8509 | 1275lm | 5028± 283K | ||||||||||
| 8寸 | MDS-01A80W018-8309 | Φ236*H50mm 开孔189mm |
AC100-240V/50-60Hz | 20W± 2W | 1600lm | SMD2835/ 0.2W(120PCS) | ≧80 | 3045± 175K | >0.9 | 12pcs | 52*26.5* 52.5 | 8.5kgs |
| MDS-01A80W018-8409 | 1600lm | 3985± 275K | ||||||||||
| MDS-01A80W018-8509 | 1700lm | 5028± 283K | ||||||||||
| 8寸 | MDS-01A80W024-8309 | Φ236*H50mm 开孔189mm |
AC100-240V/50-60Hz | 24W± 2.4W | 1920lm | SMD2835/ 0.2W(150PCS) | ≧80 | 3045± 175K | >0.9 | 12pcs | 52*26.5* 52.5 | 8.5kgs |
| MDS-01A80W024-8409 | 1920lm | 3985± 275K | ||||||||||
| MDS-01A80W024-8509 | 2040lm | 5028± 283K | ||||||||||
典雅B系列
 |
Model | Dimension | Input Voltage |
Power | Luminous Flux |
Light Aource |
CRI | CCT | Power Factor |
包装资料 | ||
| 装箱率 | 外箱尺寸 | 毛重 | ||||||||||
| 4寸 | MDS-01B40W009-8309 | Φ135*H75mm 开孔102mm | AC100-240V/50-60Hz | 9W± 0.9W | 720lm | SMD2835/ 0.2W(63PCS) | ≧80 | 3045± 175K | >0.9 | 12pcs | 52*16* 31.5 | 3.4kgs |
| MDS-01B40W009-8409 | 720lm | 3985± 275K | ||||||||||
| MDS-01B40W009-8509 | 765lm | 5028± 283K | ||||||||||
| 6寸 | MDS-01B60W015-8309 | Φ180*H75mm 开孔152mm | AC100-240V/50-60Hz | 15W± 1.5W | 1200lm | SMD2835/ 0.2W(96PCS) | ≧80 | 3045± 175K | >0.9 | 12pcs | 52*21* 41 | 5.2kgs |
| MDS-01B60W015-8409 | 1200lm | 3985± 275K | ||||||||||
| MDS-01B60W015-8509 | 1275lm | 5028± 283K | ||||||||||
| 8寸 | MDS-01B80W018-8309 | Φ236*H80mm 开孔189mm | AC100-240V/50-60Hz | 20W± 2W | 1600lm | SMD2835/ 0.2W(120PCS) | ≧80 | 3045± 175K | >0.9 | 12pcs | 52*26.5* 52.5 | 8.5kgs |
| MDS-01B80W018-8409 | 1600lm | 3985± 275K | ||||||||||
| MDS-01B80W018-8509 | 1700lm | 5028± 283K | ||||||||||
| 8寸 | MDS-01B80W024-8309 | Φ236*H80mm 开孔189mm | AC100-240V/50-60Hz | 24W± 2.4W | 1920lm | SMD2835/ 0.2W(150PCS) | ≧80 | 3045± 175K | >0.9 | 12pcs | 52*26.5* 52.5 | 8.5kgs |
| MDS-01B80W024-8409 | 1920lm | 3985± 275K | ||||||||||
| MDS-01B80W024-8509 | 2040lm | 5028± 283K | ||||||||||
